7 Inch IPS Screen HD AHD Sunshade Car Surveillance Monitor With 2 Channels Video Input Parking Camera Assistance System

IPS Monitor Excellent 178¡ã Full-view Monitor technology

178¡ã Wider viewing angles

Faster response times

Better color/contrast than many VA and TN panels

Outstanding color accuracy and screen consistency

This monitor supports mirrored image Monitor.

You can change the rear view image displayed by the rear view camera to the front view image.

Convenient Monitor installation.

Tips: We send the LED rear view camera by default. If you need a front view camera or don't need an LED, please contact .

We use the wire which update from standard 4mm to be 4.5mm, longer life lt will be. Inside of the wire much more copper wire covered with special tinfoil wrap up. Avoid the loose of the signal. Great signal will be no matter wherever you are in.

AHD Car Camera:

Sensitive components: 1/4 inch OV9712

Effective pixels: 1920¡Á1080P

Signal format: PAL/NTSC

Image horizontal Picture Clarity: 130W pixels

Video output: AHD VIDEO (720P)

Night Vision: Starlight Night Vision. The visible distance is greater than 20 meters.

Night Vision Image : Automatic Gain Control, Auto White Balance, Auto Backlight Compensation .

Exposure method: PAL: 1/50~/100000 seconds NTSC: 1/60~1/10000 seconds can be set

Lens: 14/16MM

Low illumination: 0.01Lux

Signal to noise ratio: 69dB

Working power supply: DC12V-24V

Working temperature: -20 ¡ã C ~ +50 ¡ã C

Maximum power: 3W

Video signal: Supports AHD and CVBS signals.

Screen size: 7-inch screen

Format: 16:9

Screen brightness: 500CD / M2

Effective pixels of the screen: 1024*600

IPS Screen: Support

Signal format: PAL / NTSC

Night vision image: automatic gain control, automatic white balance, automatic backlight compensation.

Power supply voltage: 12V-30V
